Intermec EasyCoder PX4i User Manual

Chapter 2 — Installation
14 EasyCoder PX4i Bar Code Label Printer User’s Guide (Fingerprint Version)
In application programs created using the Intermec Fingerprint
programming language, the keys can be assigned to various
functions or be disabled individually. Since one key is assigned as
shift key, up to 44 different key combinations are possible. An
audible signal, which can be turned off if so desired,
acknowledges that a key has been pressed.
+
Interrupt a running Fingerprint program.
Enter Setup Mode. For more information, see
“Setup Mode” on page 77.
Feed out a blank label or the equivalent.
+
Perform a Testfeed (feed a blank label and
adjust the media feed).
Display error messages, Intermec
Ready-To-Work status, and communication
channel information.
Scroll between types of information after
pressing F5/i. Possible error messages and
information on active communications
channels are shown in a loop.
Keyboard Buttons (continued)
Button Function
Keyboard Color Code
Yellow Operation of the printer (operator level)
Green Setup or service (site or service technician level)
White Data input to printer (operator or technician level)

Intermec EasyCoder PX4i Specifications

General

Print technology	Direct thermal
Maximum resolution	300 x 300 DPI
Display	LCD
Product color	Silver
Keyboard layout	Numeric
Standard interfaces	RS-232, USB 2.0
Internal memory	16 MB
Media thickness	2.4/10 mm
Maximum label width	120 mm
Maximum label length	2.7 m
Maximum roll diameter	213 mm
Supported network protocols	TCP/IP, LPR/LPD, FTP, BOOTP, DHCP, HTTP, SNMPv3, SMTP, SNMP-MIB II
Power requirements	90 - 265 VAC, 45 - 65Hz
Power consumption (standby)	20 W
Power consumption (printing)	125 W
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	40 - 104 °F
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Depth	482 mm
Width	238 mm
Height	275 mm
Weight	12850 g
