Appendix A — Specifications and Reading Distances
94 SG20B Cordless Scanner + Bluetooth Base Station User’s Guide
SG20B2D, SG20B2DHC
Symbology Density Minimum Distance Maximum Distance
Code 39 0.1 mm (4 mils)
0.125 mm (5 mils)
0.5 mm (20 mils)
1 mm (40 mils)
3.5 cm (1.38 in)
2 cm (0.79 in)
4 cm (1.57 in)
11 cm (4.33 in)
15.5 cm (6.10 in)
20 cm (7.87 in)
60 cm (23.62 in)
95 cm (37.40 in)
EAN/UPC 0.33 mm (13 mils) 3 cm (1.18 in) 38 cm (14.96 in)
PDF417 0.25 mm (10 mils)
0.38 (15 mils)
2 cm (0.79 in)
3 cm (1.18 in)
25 cm (9.84 in)
35 cm (13.78 in)
DataMatrix .025 mm (10 mils) 3 cm (1.18 in) 17 cm (6.69 in)
4"
8"
0"
4"
8"
12"
12"
cm
0.5 mm / 20 mils
1 mm / 40 mils
in
EAN/UPC
0.125mm/5 mils
10
0
10
20
20
30
30
PDF417 10 mils
Data Matrix 10 mils
0" 36"32"28"24"20"16"12"8"4" 40"
0908070605040302010 90 100
