Intermec SG20B User Manual

Chapter 2 — About the SG20 Bluetooth Base Station
18 SG20B Cordless Scanner + Bluetooth Base Station User’s Guide
About the SG20 Bluetooth Base Station
The SG20 Bluetooth Base Station is used to connect an Intermec
scanner to a non-Bluetooth host device. Data is transmitted from the
scanner to the host via the SG20 Bluetooth Base Station. The SG20
Bluetooth Base Station is also used to charge a SG20B cordless
Bluetooth scanner.
The SG20B scanner and SG20 Bluetooth Base Station are used
together (in connection) as a standalone system.
SG20 Bluetooth Base Station
Power the SG20 Bluetooth Base Station
The SG20 Bluetooth Base Station is powered through the cable
connected to a host device or an external Intermec power supply. See
“Connect the SG20 Bluetooth Base Station to a Host” on page 28
for connection details.
Intermec Ready-to-Work
indicator
USB connector
10-pin modular
connector
DC power
connector
Note: You cannot power the SG20 Bluetooth Base Station using a
standard USB cable plugged in a power outlet via a USB power
adapter.

Intermec SG20B Specifications

General

Brand	Intermec
Model	SG20B
Category	Barcode Reader
Language	English
