Chapter 2 — About the SG20 Bluetooth Base Station
24 SG20B Cordless Scanner + Bluetooth Base Station User’s Guide
Understand the Light
The SG20 Bluetooth Base Station has a blue Intermec Ready-to-
Work™ light. This light is used to indicate the status of the Bluetooth
and host connection as well as data transmission.
SG20 Bluetooth Base Station Ready-to-Work Light
Blue Intermec Ready-to-Work Indicator Description
Light State What It Means
2 flashes Power-up
On A Bluetooth connection has been established. The
SG20 Bluetooth Base Station is ready to receive data
from the scanner.
1 blink off Data has been successfully transmitted to the host.
Slow blinking Connection is incomplete (cannot charge and/or
interface with the scanner). See figure “SG20
Bluetooth Base Station Recommended Connections”
on page 23.
Off A Bluetooth connection has not been established.
Intermec Ready-to-Work
indicator
