SECTION 8 " Programming
VT220/ANSI Terminal Emulation Programmer’s Reference Guide 8-9
Table 8-4
C1 Control Characters and Wireless Station Action
Mne-
monic Hex Name Wireless Station Action
80 Ignores this code.
81 Ignores this code.
82 Ignores this code.
83 Ignores this code.
IND 84 Index Moves cursor down one line in same co-
lumn. If cursor is at bottom margin, dis-
play performs a scroll up.
NEL 85 Next line Moves cursor to first position on next line.
If cursor is at bottom margin, display per-
forms a scroll up.
SSA 86 Start of selected area Selects which characters on the current
page the wireless station can send to the
host.
ESA 87 End of selected area Ends the selected area that is sent to the
host when forms are created for
VT330/VT340 terminal emulation.
HTS 88 Horizontal tab set Sets one horizontal tab stop at the column
where the cursor is.
HTJ 89 Horizontal tab with
justify
Ignores this code.
VTS 8A Vertical tabulation set Ignores this code.
PLD 8B Partial line down Ignores this code.
PLU 8C Partial line up Ignores this code.
RI 8D Reverse index Moves cursor up one line in same column.
If cursor is at top margin, display performs
a scroll down.
SS2 8E Single shift 2 Temporarily invokes G2 character set into
GL for the next graphic character. G2 is
designated by a select character set (SCS)
sequence.
