SECTION 8 " Programming
VT220/ANSI Terminal Emulation Programmer’s Reference Guide 8-53
If this information is entered on the form:
111111111 for “LIP:”
2222222222 for “Item:”
3333 for “Lot:”
44444444 for “Qty:”
The data stream will be sent to the host as indicated in the
following chart. (If guarded area transfer mode (GATM) is
reset, then the record separator is processed as a protected
field entry.)
Sequence Description
RS Protected field Line 1.
RS First protected field Line 2.
111111111 Selected field Line 2.
RS Second protected field Line 2.
RS First protected field Line 3.
2222222222 Selected field Line 3.
RS Second protected field Line 3.
RS First protected field Line 4.
3333 Selected field Line 4.
RS Second protected field Line 4.
RS First protected field Line 5.
44444444 Selected field Line 5.
RS Second protected field Line 5.
RS Protected field Line 6.
RS Protected field Line 7.
RS Protected field Line 8.
