SECTION 8 " Programming
8-52 VT220/ANSI Terminal Emulation Programmer’s Reference Guide
(Continued)
Sequence Description
ESC W End protected area.
ESC [ 1 C Move cursor forward one position.
ESC F Start selected area.
ESC [ 4; 9 H Move cursor to Row 4, Column 9.
ESC G End selected area.
ESC V Start protected area.
ESC [ 5; 1 H Move cursor to Row 5, Column 1.
“Qty:” Display literal.
ESC [ 1 D Move cursor back one position.
ESC W End protected area.
ESC [ 1 C Move cursor forward one position.
ESC F Start selected area.
ESC [ 5; 13 H Move cursor to Row 5, Column 13.
ESC G End selected area.
ESC V Start protected area.
ESC [ 24; 80 H Move cursor to Row 24, Column 80.
ESC W End protected area.
ESC [ 26 $ | Set the number of columns to 26.
ESC [ 1; 8 r Set top at 1, bottom at 8 rows.
ESC [ 3 g
Clear tab stops.
ESC [ 2; 5 H Move cursor to Row 2, Column 5.
