Invacare STORM - Opening the Rear Light Cover

34
8.1.4 Opening the rear light cover
Requirements:
• 4 mm Allen key
• socket spanner, 13 mm
Dismantling the rear light cover:
• Remove the rear and centre cover as described in chapters 8.1.1 and Fehler! Verweisquelle
konnte nicht gefunden werden..
• Loosen the nut (1) using a 13 mm socket spanner.
Refitting the rear light cover:
• Refit the parts in reverse order.
• Now tighten all the screws finger-tight again.
