8.9.2 Adjusting the seat depth
Note
The seat depth can be adjusted in stages between 38 and 53 cm.
Please also observe preceding chapter Fehler! Verweisquelle konnte nicht gefunden
werden. on “adjusting the seat depth”.
Note
Depending on the width and depth of the seat, the splash guards must also be replaced. Please
also observe chapter 8.1.5 on “replacing the splash guard”.
Requirements:
• 4 mm Allen key
• 8 mm jaw spanner
•
•
•
Note
Certain holes in the seat support must be used for the screws depending on the desired seat
depth. It may possibly be necessary to replace the seat support plates.
• Use the following illustration and the table to determine which holes must be used for the
desired seat depth and whether the seat support plates possibly have to be replaced.
Seat frame front:
Seat frame rear:
