8.11.4 Replacing the microswitch
Requirements:
• 4 mm Allen key
• Size 2 Phillips recessed head spanner
•
Dismantling the microswitch:
• Loosen and remove the six Allen screws on the backrest plastic cover using a 4 mm Allen key.
• Remove the plastic cover.
•
• Pull the plugs (2) out of the microswitch (1).
• Loosen and remove the two Phillips screws (3)
• Replace the microswitch.
Refitting the planetary gear:
• Refit the parts in reverse order.
• To conclude, check all the mobility aid functions.
