8.10.2 Replacing the EasyAdapt back
Requirements:
• 5 mm Allen key
•
•
•
Dismantling the back unit:
• Remove the back cushion.
• Pull the actuator cable out of the actuator module under the seat.
• Pull the cable out of the mobility aid. Remove any cable ties which are fitted.
• Loosen and remove the Allen screws (5) incl. the washers on the left and right side of the seat.
• Carefully remove the back section (1) together with the lower part (2) from the seat support
(3). The two parts are interconnected via the arm (4).
Refitting the back unit:
• Refit the parts in reverse order.
• To conclude, check all the mobility aid functions.
