8.2.5 Replacing the front bulb holder (conventional lighting unit)
Requirements:
•
• 8 mm spanner
Dismantling the bulbholder:
• Loosen the two cap nuts (2) using an 8 mm spanner and remove the headlight with the
mounting from the rubber bumpers.
• There are two Phillips screws, (cannot be seen in the picture), that fasten the headlight to the
mounting. Loosen the two Phillips screws in order to remove the headlight from the mounting.
• Replace the mounting.
Refitting the bulbholder:
• Refit the parts in reverse order.
• Now tighten all the screws finger-tight again.
• Check all vehicle functions.
• Adjust the headlight roughly using the grid. The user can carry out the final adjustment following
the operating manual.
