80
8.6.2 Replacing the electric lifting column
CAUTION: Danger of crushing!
• The mobility aid and the seat are very heavy. You should seek help from a second person!
CAUTION: Injury hazard if the vehicle starts moving unintentionally during repair work!
• Safeguard the vehicle that has been placed on its side against overturning.
Requirements:
• 4 mm Allen key
• T40 torx wrench
•
•
Dismantling the lifting column:
• Remove the rear battery compartment cover as described in chapter 8.1.1.
• Remove the centre battery compartment cover as described in chapter Fehler!
Verweisquelle konnte nicht gefunden werden..
• Remove the front battery compartment cover as described in chapter 8.1.3.
• Remove the seat as described in chapter 8.5.1 or 8.5.3 respectively.
• Release the lifting column cable from the actuator module.
• Open the cable clamps and expose the cable.
• Obtain the aid of a second person to place the mobility aid on its side and safeguard it against
overturning.
