8.4.4 Replacing the actuator module under the seat
The actuator module is optional.
Requirements:
• 4 mm Allen key
Removing the tilt module:
• If possible, use the lifter to move the seat to the uppermost position.
• Carefully note the location of the cable and the connection locations of the various plugs.
Either mark each plug and socket, or take a photograph with a digital camera.
• Pull the plug (1) out of the actuator module.
• Remove the two Allen screws (2).
• Replace the actuator module.
Removing the tilt module:
• Refit the parts in reverse order.
• Plug all the plugs into their old positions.
• To conclude, check all the mobility aid functions.
•
•
