8.2.9 Replacing the rear bulb holder (conventional lighting unit)
Requirements:
•
• 8 mm socket spanner
• 13 mm socket spanner
Dismantling the bulbholder:
• Remove the complete rear light as described in Chapter 8.2.8.
• Undo the two Allen screws (1) with a 4 mm socket spanner and remove the screws.
• Replace the bulbholder (2).
Refitting the bulbholder:
• Refit the parts in reverse order.
• Check all vehicle functions.
