39
8.2.3 Replacing the complete front headlight (conventional lighting unit)
Requirements:
•
• 8 mm spanner
• 4 mm Allen key
•
•
Removing the front headlight:
• Remove the rear and centre cover as described in chapters 8.1.1 and Fehler! Verweisquelle
konnte nicht gefunden werden..
• Carefully note the location of the cable and the connection locations of the various plugs.
Either mark each plug and socket, or take a photograph with a digital camera.
• Loosen the cable leading to the lighting PCB from the front headlight affected (2).
• Open the cable clamps (1), remove all cable ties and pull the cable out of the mobility aid.
