• Loosen and remove the four torx screws (2) on the underside of the column (3).
• Lift off the coverplate (1).
Note
The cover plate has four flaps pointing downward. There are two tapped holes on each flap for
the screws (2). By selecting the upper or lower holes, the seat can be adjusted to two different
heights.
• Attach the cover plate (1).
• Install the screws (2) in such a way that the cover plate is flush fitted or is somewhat elevated
depending on the desired seat height.
• Refit the other parts in reverse order.
• To conclude, check all the mobility aid functions.
•
