INVT GD300L Series User Manual

Goodrive300-LIFT series inverter Communication protocol
-125-
Function
instruction
Address
definition
Data meaning instruction
R/W
property
rotation (0–Fmax, unit: 0.01Hz)
2006H
The upper limit frequency setting during reverse
rotation (0–Fmax, unit: 0.01Hz)
W/R
2007H
The upper limit torque of electromotion torque
(0–3000, 1000 corresponds to the 100.0% of the
rated current of the motor)
W/R
2008H
The upper limit torque of braking torque (0–3000,
1000 corresponds to the 100.0% of the rated current
of the motor)
W/R
2009H
Special control command word
Bit0–1:=00: motor 1 =01: motor 2
=10: motor 3 =11: motor 4
Bit2:=1 torque control prohibit
=0: torque control prohibit invalid
Bit3:=1 power consumption clear
=0:no power consumption clear
Bit4:=1 pre-exciting enabling
=0: pre-exciting disabling
Bit5:=1 DC braking enabling
=0: DC braking disabling
W/R
200AH
Virtual input terminal command, range: 0x000–0x1FF
W/R
200BH
Virtual output terminal command , range: 0x00–0x0F
W/R
200CH
Voltage setting value(special for V/F separation)
(0–1000, 1000 corresponds to the 100.0%)
W/R
200DH
AO output setting 1
(-1000–1000, 1000 corresponds to 100.0%)
W/R
200EH
AO output setting 2
(-1000–1000, 1000 corresponds to 100.0%)
W/R
SW 1 of the
inverter
2100H
0001H:forward running
R
0002H:forward running
0003H:stop
0004H:fault
0005H: POFF state
0006H: pre-exciting state
