INVT GD300L Series User Manual

Goodrive300-LIFT series inverter Communication protocol
-126-
Function
instruction
Address
definition
Data meaning instruction
R/W
property
SW 2 of the
inverter
2101H
Bit0: =0: ready for operation =1: not ready for
operation
Bi1–2:=00:motor 1 =01:motor 2
=10:motor 3 =11:motor 4
Bit3: =0:asynchronous motor =1:synchronous
motor
Bit4: =0:pre-alarm without overload =1:overload
pre-alarm
Bit5–Bit6: =00: keypad control
=01: terminal control
=10: communication control
R
Fault code of the
inverter
2102H
See the fault type instruction
R
Identifying code
of the inverter
2103H
GD300-----0x010a
R
Operation
frequency
3000H
0–Fmax (unit: 0.01Hz)
Compatible with
CHF100A/CHV100
communication
address
R
Setting frequency
3001H
0–Fmax (unit: 0.01Hz)
R
Bus voltage
3002H
0.0–2000.0V (unit: 0.1V)
R
Output voltage
3003H
0–1200V (unit: 1V)
R
Output current
3004H
0.0–3000.0A (unit: 0.1A)
R
Rotation speed
3005H
0–65535 (unit: 1RPM)
R
Output power
3006H
-300.0–300.0% (unit: 0.1%)
R
Output torque
3007H
-250.0–250.0% (unit: 0.1%)
R
Close loop setting
3008H
-100.0–100.0% (unit: 0.1%)
R
Close loop
feedback
3009H
-100.0–100.0% (unit: 0.1%)
R
Input IO state
300AH
000–1FF
R
Output IO state
300BH
000–1FF
R
Analog input 1
300CH
0.00–10.00V (unit: 0.01V)
R
Analog input 2
300DH
0.00–10.00V (unit: 0.01V)
R
Analog input 3
300EH
-10.00–10.00V (unit: 0.01V)
R
Analog input 4
300FH
R
Read input of
3010H
0.00–50.00kHz (unit: 0.01Hz)
R
