INVT GD300L Series User Manual

Goodrive300-LIFT series inverter Commissioning guidelines
-78-
Function code
Name
Recommended
Remarks
P00.00
Speed control mode
0 or 3
0: Open-loop control for
asynchronous motors; 3:
Closed-loop control for
synchronous motors
P00.01
Running command
channel
1
P00.02
Lift rated speed
Based on lift speed
P00.03
Speed command
3
P00.04
Max. output
frequency
50.00Hz
P02.00
Motor type
Based on the
motor.
P02.01
Motor rated power
Tractor parameter
name plate
P02.02
Motor rated
frequency
Tractor parameter
name plate
P02.03
Motor rated rotation
speed
Tractor parameter
name plate
P02.04
Motor rated voltage
Tractor parameter
name plate
P02.05
Motor rated current
Tractor parameter
name plate
P20.00
Encoder type
0
P20.01
Encoder pulse
quantity
Based on the
encoder model
P20.02
Encoder direction
0
P05.01
S1
1
Up
P05.02
S2
2
Down
P05.03
S3
19
Enable
P05.04
S4
8
Multi-step speed 1
P05.05
S5
9
Multi-step speed 2
P05.06
S6
10
Multi-step speed 3
P05.07
S7
17
Contactor feedback
P05.08
S8
18
Brake feedback
P05.12
HDI
3
Maintenance
P06.01
Y output
1
Running feedback output
P06.04
RO1 relay output
4
Fault output
