INVT Goodrive30 VFD Series User Manual

Goodrive30 Series VFD Function parameter list
-104-
Function
code
Name
Description
Default
Modify
code.
Setting range: 0.0%–100.0% (of the motor rated
current)
P13.04
Pull-in
current
switchover
frequency
The function code indicates the valid frequency
threshold for switching between pull-in current 1
and pull-in current 2.
Setting range: 0.00Hz–P00.03 (max. output
frequency)
10.00 Hz
○
P13.05
High-freque
ncy
superposin
g frequency
(reserved)
200–1000Hz
500Hz
◎
P13.06
Pulse
superposin
g
voltage
0.0–300.0% (of the motor rated voltage)
40.0%
◎
P13.07
Reserved
0–65535
0
○
P13.08
Control
parameter 1
0–65535
0
○
P13.09
Control
parameter 2
0–655.35
2.00
○
P13.10
Reserved
0–65535
0
○
P13.11
Maladjustm
ent
detection
time
The function code is used to adjust the
responsiveness of anti-maladjustment function. If
the load inertia is large, increase the value of the
function code properly, however, the
responsiveness may slow down accordingly.
Setting range: 0.0–10.0s
0.5s
○
P13.12
High-freque
ncy
compensati
on
coefficient
The function code is valid when the motor speed
exceeds the rated speed. If motor oscillation
occurred, adjust the function code properly.
Setting range: 0.0–100.0%
0.0%
○
P13.13
Short-circuit
braking
current
When the VFD starts in direct start mode
(P01.00=0), set P13.14 to a non-zero value to
enter short-circuit braking.
0.0%
○
