Goodrive30 Series VFD Function parameter list
-105-
Function
code
Name
Description
Default
Modify
P13.14
Hold time of
short-circuit
braking
before start
During stop, if the running frequency of VFD is
lower than the starting frequency of brake for
stop, set P13.15 to a non-zero value to enter
short-circuit braking for stop, and then carry out
DC braking in the time set by P01.12. (Refer to
the descriptions for P01.09–P01.12.)
Setting range of P13.13: 0.0–150.0% (VFD)
Setting range of P13.14: 0.00–50.00s
Setting range of P13.15: 0.00–50.00s
0.00s
○
P13.15
Hold time of
short-circuit
braking for
stop
0.00s
○
P14 group Serial communication
Function
code
Name
Description
Default
Modify
P14.00
Local
communicat
ion address
Setting range: 1–247
When the master writes the slave
communication address to 0 indicating a
broadcast address in a frame, all the salves on
the Modbus bus receive the frame but do not
respond to it.
Local communication address is unique in the
communication network, which is the basis for
point-to-point communication between the upper
computer and the VFD.
Note: The communication address of a slave
cannot be set to 0.
1
○
P14.01
Communica
tion baud
rate
The function code is used to set the data
transmission speed between the upper computer
and the VFD.
0: 1200BPS
1: 2400BPS
2: 4800BPS
3: 9600BPS
4: 19200BPS
5: 38400BPS
6: 57600BPS
Note: The baud rate set on the VFD must be
consistent with that on the upper computer.
Otherwise, the communication fails. A greater
baud rate indicates faster communication.
4
○
