Goodrive30 Series VFD Function parameter list
-33-
the VFD.) If password protection is not in locked state, you can change the password any time.
You can set P07.00 to 0 to cancel the user password. When P07.00 is set to a non-zero value
during power-on, parameters are prevented from being modified by using the user password
function. When you modify function parameters through serial communication, the user
password protection function is also applicable and compliant with the same rule.
Note: The VFD automatically checks and constrains the modification of parameters, which
helps prevent incorrect modifications.
P00 group Basic functions
0: SVC mode 0 (applicable to AM and SM)
There is no need to install encoders. It is suitable
in applications with low frequency, big torque and
high speed control accuracy for accurate speed
and torque control. Compared to mode 1, this
mode is more suitable for the applications which
need medium and small power.
1: SVC mode 1 (applicable to AM)
There is no need to install encoders. It is suitable
in applications with high speed control accuracy
for accurate speed and torque control at all
power ratings.
2: SVPWM control mode
There is no need to install encoders. It can
improve the control accuracy with the
advantages of stable operation, valid
low-frequency torque boost and current vibration
suppression and the functions of slip
compensation and voltage adjustment.
Note:
AM: Asynchronous motor (AM)
SM: Synchronous motor (SM)
Channel of
running
commands
The function code is used to select the channel
of VFD control commands.
Control commands of the VFD include: start,
stop, forward/reverse rotating, jogging, and fault
reset.
0: Keypad (the "LOCAL/REMOT" indicator is off)
The running commands are controlled through
