Goodrive30 Series VFD Function parameter list
-90-
Function
code
Name
Description
Default
Modify
magnetic flux.
The VFD monitors the state of the motor
continuously even during the magnetic flux
period. So the magnetic flux can be used for
motor stop, as well as for motor rotation speed
change. Its other advantages include: Braking is
performed immediately after the stop command
is given. The braking can be started without
waiting for magnetic flux weakening.
The cooling is better. The current of the stator
other than the rotor increases during magnetic
flux braking, while the cooling of the stator is
more effective than the rotor.
P08.51
VFD input
power
factor
This function code is used to adjust the displayed
current on the AC input side.
Setting range: 0.00–1.00
0.56
○
P09 group PID control
Function
code
Name
Description
Default
Modify
P09.00
PID
reference
source
When the frequency command selection
(P00.06, P00.07) is 7 or the voltage setting
channel selection (P04.27) is 6, the VFD is
process PID controlled.
The function code determines the target given
channel during the PID process.
0: Keypad (P09.01)
1: AI1
2: AI2
3: AI3
4: High speed pulse HDI
5: Multi-step running
6: Modbus communication
7–9: Reserved
The set target of process PID is a relative value,
for which 100% equals to 100% of the feedback
signal of the controlled system.
The system always calculates a related value
(0–100.0%).
0
○
