Goodrive30 Series VFD Function parameter list
-32-
5 Function parameter list
The function parameters of Goodrive30 series VFD have been divided into 30 groups
(P00–P29) according to the function, of which P18–P28 are reserved. Each function group
contains certain function codes. A three-level menu style is applied to function codes. For
example, "P08.08" indicates the 8th function code in the P8 group. The P29 group consist of
factory function parameters, which are user inaccessible.
The function group numbers correspond to the level-1 menus, the function codes correspond
to the level-2 menus, and the function parameters correspond to the level-3 menus.
1. The content of the function code table is as follows:
Column 1 "Function code ": Code of the function group and parameter.
Column 2 "Name": Full name of the function parameter.
Column 3 "Description": Detailed description of the function parameter.
Column 4 "Default": Initial value set in factory.
Column 5 "Modify": Whether the function parameter can be modified, and conditions for the
modification.
"○" indicates that the value of the parameter can be modified when the VFD is in stopped or
running state.
"◎" indicates that the value of the parameter cannot be modified when the VFD is in running
state.
"●" indicates that the value of the parameter is detected and recorded, and cannot be
modified.
(The VFD automatically checks and constrains the modification of parameters, which helps
prevent incorrect modifications.)
2. The parameters adopt the decimal system (DEC). If the hexadecimal system is adopted, the
data in each digit is independent from each other during parameter editing. The values of
some of the digits can be hexadecimal (0–F).
3. "Default" indicates the factory setting of the function parameter. If the value of the parameter
is detected or recorded, the value cannot be restored to the factory setting.
4. To better protect parameters, the VFD provides the password protection function. After a
password is set (that is, P07.00 is set to a non-zero value), "0.0.0.0.0" is displayed when you
press the PRG/ESC key to enter the function code editing interface. You need to enter the
correct user password to enter the interface. For the factory parameters, you need to enter the
correct factory password to enter the interface. (You are not advised to modify the factory
parameters. Incorrect parameter setting may cause operation exceptions or even damage to
