Goodrive30 Series VFD Optional peripheral accessories
-161-
VFD model
Input reactor
Output reactor
GD30-5R5G-4
ACL2-5R5-4
OCL2-5R5-4
GD30-7R5G-4
ACL2-7R5-4
OCL2-7R5-4
GD30-011G-4
ACL2-011-4
OCL2-011-4
GD30-015G-4
ACL2-015-4
OCL2-015-4
GD30-018G-4
ACL2-018-4
OCL2-018-4
GD30-022G-4
ACL2-022-4
OCL2-022-4
GD30-030G-4
ACL2-030-4
OCL2-030-4
GD30-037G-4
ACL2-037-4
OCL2-037-4
GD30-045G-4
ACL2-045-4
OCL2-045-4
GD30-055G-4
ACL2-055-4
OCL2-055-4
GD30-075G-4
ACL2-075-4
OCL2-075-4
GD30-090G-4
ACL2-110-4
OCL2-110-4
GD30-110G-4
ACL2-110-4
OCL2-110-4
Note:
The rated input voltage drop of input reactors is 2%±15% while the rated output voltage
drop of output reactors is 1%±15%.
The preceding table describes external accessories. You need to specify the ones you
choose when purchasing accessories.
C.6 Filters
C.6.1 C3 Filter model description
BA C D E F
G
Field
identifier
Field description
A
FLT: Name of the VFD filter series
B
Filter type
P: Power input filter
L: Output filter
C
Voltage class
S2: AC 1PH 220V(-15%)240V(+10%)
04: AC 3PH 380V(-15%)440V(+10%)
D
3-digit development serial number. For example, 003 stands for the serial
number of C3 filters in development
E
Filter performance
L: General
H: High-performance
