INVT Goodrive30 VFD Series User Manual

Goodrive30 Series VFD Function parameter list
-70-
Function
code
Name
Description
Default
Modify
of HDI low
frequency
setting
P05.52
Upper limit
frequency
of HDI
P05.50–50.000kHz
50.000kHz
○
P05.53
Correspond
ing setting
of upper
limit
frequency
of HDI
-100.0%–100.0%
100.0%
○
P05.54
HDI
frequency
input filter
time
0.000s–10.000s
0.010s
○
P06 group Output terminals
Function
code
Name
Description
Default
Modify
P06.00
HDO output
type
P06.00 is the function selection of the
high-speed pulse output terminals.
output terminals.
0: Open collector high-speed pulse output. The
max. frequency of pulse is 50.00kHz. For details
about the related functions, see P06.27–P06.31.
1: Open collector output. For details about the
related functions, see P06.02.
0
◎
P06.01
Y1 output
0: Invalid
1: Running
2: Running forward
3: Running reversely
4: Jogging
5: VFD in fault
6: Frequency level detection FDT1
7: Frequency level detection FDT2
8: Frequency reached
9: Running in zero speed
10: Upper limit frequency reached
0
○
P06.03
RO1 output
1
○
P06.04
RO2 output
5
○
