INVT Goodrive30 VFD Series User Manual

Goodrive30 Series VFD Function parameter list
-107-
Function
code
Name
Description
Default
Modify
an alarm (applicable to any mode)
P14.06
Communica
tion
processing
action
0x00–0x11
Ones place:
0: Respond to write operations. The VFD
responds to read and write commands of the
upper computer.
1: Not respond to write operations. The VFD
responds only to the read commands of the
upper computer. This mode can improve the
communication efficiency.
Tens place:
0: Communication encryption is invalid.
1: Communication encryption is valid.
0x00
○
P17 group Status viewing
Function
code
Name
Description
Default
Modify
P17.00
Set
frequency
Displays current set frequency of the VFD.
Range:0.00Hz–P00.03
0.00Hz
●
P17.01
Output
frequency
Displays current output frequency of the VFD.
Range: 0.00Hz–P00.03
0.00Hz
●
P17.02
Ramp
reference
frequency
Displays current ramp reference frequency of the
VFD.
Range: 0.00Hz–P00.03
0.00Hz
●
P17.03
Output
voltage
Displays current output voltage of the VFD.
Range: 0–1200V
0V
●
P17.04
Output
current
Displays the valid value of current output current
of the VFD.
Range: 0.0–3000.0A
0.0A
●
P17.05
Motor
speed
Displays current motor speed.
Range: 0–65535RPM
0 RPM
●
P17.06
Torque
current
Displays current torque current of the VFD.
Range: -3000.0–3000.0A
0.0A
●
P17.07
Exciting
current
Displays current exciting current of the VFD.
Range: -3000.0–3000.0A
0.0A
●
P17.08
Motor
power
Displays current motor power; 100% relative to
rated motor power, positive value is motoring
state, negative value is generating state.
0.0%
●
