INVT Goodrive30 VFD Series User Manual

Goodrive30 Series VFD Function parameter list
-106-
Function
code
Name
Description
Default
Modify
P14.02
Data bit
check
The data format set on the VFD must be
consistent with that on the upper computer.
Otherwise, the communication fails.
0: No check (N, 8, 1) for RTU
1: Even check (E, 8, 1) for RTU
2: Odd check (O, 8, 1) for RTU
3: No check (N, 8, 2) for RTU
4: Even check (E, 8, 2) for RTU
5: Odd check (O, 8, 2) for RTU
1
○
P14.03
Communica
tion
response
delay
0–200ms
The function code indicates the communication
response delay, that is, the interval from when
the VFD completes receiving data to when it
sends response data to the upper computer. If
the response delay is shorter than the VFD
processing time, the VFD sends response data
to the upper computer after processing data. If
the delay is longer than the VFD processing
time, the VFD does not send response data to
the upper computer until the delay is reached
although data has been processed.
5
○
P14.04
Communica
tion
overtime
fault time
0.0 (invalid), 0.1–60.0s
When the function code is set to 0.0, the
communication timeout time is invalid.
When the function code is set a non-zero value,
the rectifier reports the "485 communication
fault" (CE) if the communication interval exceeds
the value.
In general, the function code is set to 0.0. When
continuous communication is required, you can
set the function code to monitor communication
status.
0.0s
○
P14.05
Transmissio
n error
processing
0: Report an alarm and coast to stop
1: Keep running without reporting an alarm
2: Stop in enabled stop mode without reporting
an alarm (applicable only to communication
mode)
3: Stop in enabled stop mode without reporting
0
○
