INVT Goodrive30 VFD Series User Manual

Goodrive30 Series VFD Communication protocol
-134-
 The service life of the Electrically Erasable Programmable Read-Only Memory (EEPROM)
may be reduced if it is frequently used for storage. Some function codes do not need to be
stored during communication. The application requirements can be met by modifying the
value of the on-chip RAM, that is, modifying the MSB of the corresponding function code
address from 0 to 1. For example, if P00.07 is not to be stored in the EEPROM, you need
only to modify the value in the RAM, that is, set the address to 8007H. The address can be
used only for writing data to the on-chip RAM, and it is invalid when used for reading data.
7.4.2 Description of other function addresses
In addition to modifying the parameters of the VFD, the master can also control the VFD, such
as starting and stopping it, and monitoring the operation status of the VFD. The following table
describes other function parameters.
Function
Address
Data description
R/W
characteristics
Communication-based
control command
2000H
0001H: Forward running
R/W
0002H: Reverse running
0003H: Forward jogging
0004H: Reverse jogging
0005H: Stop
0006H: Coast to stop
0007H: Fault reset
0008H: Jogging to stop
Communication-based
value setting
2001H
Communication-based frequency setting
(0–Fmax, unit: 0.01 Hz)
R/W
2002H
PID setting, range (0–1000, 1000
corresponding to 100.0%)
2003H
PID feedback, range (0–1000, 1000
corresponding to 100.0%)
R/W
2004H
Torque setting (-3000–+3000, 1000
corresponding to 100.0% of the motor
rated current)
R/W
2005H
Setting of the upper limit of the forward
running frequency (0–Fmax, unit: 0.01
Hz)
R/W
2006H
Setting of the upper limit of the reverse
running frequency (0–Fmax, unit: 0.01
Hz)
R/W
2007H
Upper limit of the electromotion torque
(0–3000, 1000 corresponding to 100.0%
of the motor rated current)
R/W
