INVT Goodrive30 VFD Series User Manual

Goodrive30 Series VFD Communication protocol
-135-
Function
Address
Data description
R/W
characteristics
2008H
Upper limit of the brake torque (0–3000,
1000 corresponding to 100.0% of the
motor rated current)
R/W
2009H
Special control command word:
Bit0–1: =00: Motor 1 =01: Motor 2
=10: Motor 3 =11: Motor 4
Bit2: =1 Disable torque control
=0: Enable torque control
Bit3: =1 Clear electricity consumption
=0: Not clear electricity
consumption
Bit4: =1 Pre-excitation
=0: Disable pre-excitation
Bit5: =1 DC brake =0: Disable DC brake
R/W
200AH
Virtual input terminal command, range:
0x000–0x1FF
R/W
200BH
Virtual output terminal command, range:
0x00–0x0F
R/W
200CH
Voltage setting (used for V/F separation)
(0–1000, 1000 corresponding to 100.0%
of the motor rated voltage)
R/W
200DH
AO output setting 1 (-1000–+1000, 1000
corresponding to 100.0%)
R/W
200EH
AO output setting 2 (-1000–+1000, 1000
corresponding to 100.0%)
R/W
VFD status word 1
2100H
0001H: Forward running
R
0002H: Reverse running
0003H: Stopped
0004H: Faulty
0005H: POFF
0006H: Pre-excited
VFD status word 2
2101H
Bit0: =0: Not ready to run =1: Ready to
run
Bi1–2: =00: Motor 1 =01: Motor 2
=10: Reserved =11: Reserved
Bit3: =0: Asynchronous motor =1:
Synchronous motor
Bit4: =0: No overload alarm =1: Overload
R
