INVT Goodrive30 VFD Series User Manual

Goodrive30 Series VFD Communication protocol
-136-
Function
Address
Data description
R/W
characteristics
alarm
Bit5–Bit6: =00: Keypad-based control
=01: Terminal-based control
=10: Communication-based control
VFD fault code
2102H
See the description of fault types.
R
VFD identification
code
2103H
GD30-----0x0106
R
Running frequency
3000H
0–Fmax (Unit: 0.01Hz)
Compatible with
GD series,
CHF100A, and
CHV100
communication
addresses
R
Set frequency
3001H
0–Fmax (Unit: 0.01Hz)
R
Bus voltage
3002H
0.0–2000.0V (Unit:
0.1V)
R
Output voltage
3003H
0–1200V (Unit: 1V)
R
Output current
3004H
0.0–3000.0A (Unit:
0.1A)
R
Rotating speed
3005H
0–65535 (Unit: 1RPM)
R
Output power
3006H
-300.0–300.0% (Unit:
0.1%)
R
Output torque
3007H
-250.0–250.0% (Unit:
0.1%)
R
PID setting
3008H
-100.0–100.0% (Unit:
0.1%)
R
PID feedback
3009H
-100.0–100.0% (Unit:
0.1%)
R
Input IO state
300AH
000–1FF
R
Output IO state
300BH
000–1FF
R
Analog input 1
300CH
0.00–10.00V (Unit:
0.01V)
R
Analog input 2
300DH
0.00 – 10.00V (Unit:
0.01V)
R
Analog input 3
300EH
-10.00– 10.00V (Unit:
0.01V)
R
Analog input 4
300FH
Reserved
R
Read input of
3010H
0.00–50.00kHz (Unit:
R
