INVT Goodrive30 VFD Series User Manual

Goodrive30 Series VFD Function parameter list
-62-
P05 group Input terminals
Function
code
Name
Description
Default
Modify
P05.00
HDI input
type
0: HDI is high-speed pulse input. See
P05.49–P05.54.
1: HDI is digital input. See P05.09.
0
◎
P05.01
S1 terminal
function
selection
0: No function
1: Forward running (FWD)
2: Reverse running (REV)
3: 3-wire running control (SIn)
4: Forward jogging
5: Reverse jogging
6: Coast to stop
7: Fault reset
8: Running pause
9: External fault input
10: Frequency increase (UP)
11: Frequency decrease (DOWN)
12: Clear frequency increase/decrease setting
13: Switch between A setting and B setting
14: Switch between combination setting and A
setting
15: Switch between combination setting and B
setting
16: Multi-step speed terminal 1
17: Multi-step speed terminal 2
18: Multi-step speed terminal 3
19: Multi-step speed terminal 4
20: Pause multi-step speed running
21: ACC/DEC time selection 1
22: ACC/DEC time selection 2
23: Simple PLC stop reset
24: Pause simple PLC
25: Pause PID control
26: Pause wobbling frequency (stop at the
current frequency)
27: Reset wobbling frequency (return to the
center frequency)
28: Counter reset
29: Disable torque control
1
◎
P05.02
S2 terminal
function
selection
4
◎
P05.03
S3 terminal
function
selection
7
◎
P05.04
S4 terminal
function
selection
0
◎
P05.05
S5 terminal
function
selection
0
◎
P05.06
S6 terminal
function
selection
0
◎
P05.07
S7 terminal
function
selection
0
◎
P05.08
S8 terminal
function
selection
0
◎
P05.09
HDI
terminal
function
selection
0
◎
