INVT Goodrive30 VFD Series User Manual

Goodrive30 Series VFD Function parameter list
-63-
Function
code
Name
Description
Default
Modify
30: Disable ACC/DEC
31: Trigger the counter
32: Reserved
33: Clear the frequency increase/decrease
setting temporarily
34: DC braking for stop
35: Reserved
36: Switch the running command channel to
keypad
37: Switch the running command channel to
terminal
38: Switch the running command channel to
communication
39: Pre-exciting command
40: Clear electricity consumption
41: Keep electricity consumption
42–60: Reserved
61: Switch PID polarities
62–63: Reserved
P05.10
Input
terminal
polarity
The function code is used to set the polarity of
input terminals.
When a bit is 0, the input terminal is positive;
when a bit is 1, the input terminal is negative.
BIT8
BIT7
BIT6
BIT5
HDI
S8
S7
S6
BIT4
BIT3
BIT2
BIT1
BIT0
S5
S4
S3
S2
S1
Setting range: 0x000 –0x1FF
0x000
○
P05.11
Digital filter
time
The function code is used to set the filter time for
S1–S8 and HDI. In strong interference cases,
increase the value to avoid mal-operation.
Setting range: 0.000–1.000s
0.010s
○
P05.12
Virtual
terminal
setting
0x000–0x1FF (0: Disable, 1: Enable)
BIT0: S1 virtual terminal
BIT1: S2 virtual terminal
BIT2: S3 virtual terminal
BIT3: S4 virtual terminal
0x000
◎
