Goodrive30 Series VFD Installation guidelines
-15-
-40°C–+70°C, and the temperature changing rate is less than
1°C/minute.
Running
environment
condition
The installation site should meet the following requirements.
Away from electromagnetic radiation sources.
Away from oil mist, corrosive gases and combustible gases.
Ensure foreign object like metal powder, dust, oil and water will not
fall into the VFD (do not install the VFD onto combustible object like
wood).
Away from radioactive substance and combustible objects.
Away from harmful gases and liquids.
Low salt content.
No direct sunlight.
Below 1000m.
When the altitude exceeds 1000m, derate by 1% for every increase
of 100m.
When the altitude exceeds 3000m, consult the local INVT dealer or
office for details.
The max. amplitude of vibration should not exceed 5.8m/s
2
(0.6g).
Install the VFD vertically to ensure good heat dissipation effect.
Note:
The VFD must be installed in a clean and well-ventilated environment based on the IP
level.
The cooling air must be clean enough and free from corrosive gases and conductive dust.
3.1.2 Installation direction
The VFD can be installed on the wall or in a cabinet.
The VFD must be installed vertically. Check the installation position according to following
requirements. Refer to Appendix B "Dimension drawings" for dimension details.
3.1.3 Installation mode
1. Wall and rail mounting for the VFDs (1PH 220V/3PH 380V, ≤2.2KW and 3PH 220V,
≤0.75KW)
