INVT Goodrive30 VFD Series User Manual

Goodrive30 Series VFD Product overview
-10-
Field
No.
Description
Content
Voltage class
③
Voltage class
S2: AC 1PH 220V(-15%)–240V(+10%)
2: AC 3PH 220V(-15%)–240V(+10%)
4: AC 3PH 380V(-15%)–440V(+10%)
Note:
Braking units have been built in the 37kW and lower VFD models as standard configuration.
Braking units are not standard configuration for the 45–110kW VFD models. (If you want to
use braking units for these models, add suffix "-B" at the end of the model codes in your
purchase orders, for example, GD30-045G-4-B.)
2.5 Rated specifications
Model
Voltage
class
Output power
(kW)
Input current
(A)
Output current
(A)
GD30-0R4G-S2
1PH 220V
0.4
6.5
2.5
GD30-0R7G-S2
0.75
9.3
4.2
GD30-1R5G-S2
1.5
15.7
7.5
GD30-2R2G-S2
2.2
24
10
GD30-0R4G-2
3PH 220V
0.4
3.7
2.5
GD30-0R7G-2
0.75
5
4.2
GD30-1R5G-2
1.5
7.7
7.5
GD30-2R2G-2
2.2
11
10
GD30-004G-2
4
17
16
GD30-5R5G-2
5.5
21
20
GD30-7R5G-2
7.5
31
30
GD30-0R7G-4
3PH 380V
0.75
3.4
2.5
GD30-1R5G-4
1.5
5.0
4.2
GD30-2R2G-4
2.2
5.8
5.5
GD30-004G-4
4
13.5
9.5
GD30-5R5G-4
5.5
19.5
14
GD30-7R5G-4
7.5
25
18.5
GD30-011G-4
11
32
25
GD30-015G-4
15
40
32
GD30-018G-4
18.5
47
38
GD30-022G-4
22
51
45
GD30-030G-4
30
70
60
GD30-037G-4
37
80
75
GD30-045G-4
45
98
92
GD30-055G-4
55
128
115
GD30-075G-4
75
139
150
