INVT Goodrive30 VFD Series User Manual

Goodrive30 Series VFD Optional peripheral accessories
-155-
Appendix C Optional peripheral accessories
This chapter describes how to select optional accessories of the VFD.
C.1 Wiring of peripheral accessories
The following figure shows the external wiring of the VFD.
+
PB
RS485-
RS232
converter
485 +
485 -
LED keypad
Optional
Power supply
Breaker
Input reactor
Input filter
Grounding
PC
Upper PC
software
Braking
resistor
Output filter
Output reactor
Motor
Grounding
1
2
4
3
5
PRG
ESC
DATA
QUICK
JOG
SHIFT
RUN
STOP
RST
RUN/TUNEFWD/REVLOCAL/REMOT TRIP
HZ
A
V
RPM
%
Name
Description
1
2
4
3
5
PRG
ESC
DATA
QUICK
JOG
SHIFT
RUN
STOP
RST
RUN/TUNE FWD/REV LOCAL/REMOT TRIP
HZ
A
V
RPM
%
External
keypad
External keypads include the external keypads with
and without the function of parameter copying.
When the external keypad with parameter copying is
valid, the local keypad is off; when the external
keypad without parameter copying is valid, the local
and external keypads are on simultaneously.
