Goodrive30 Series VFD Safety precautions
-2-
1.3 Safety guidelines
Only qualified electricians are allowed to operate on the VFD.
Do not carry out any wiring and inspection or changing components when
the power supply is applied. Ensure all input power supply is
disconnected before wiring and checking and always wait for at least the
time designated on the VFD or until the DC bus voltage is less than 36V.
The waiting time list is as follows.
Do not refit the VFD unauthorized; otherwise, fire, electric shock or other
injury may occur.
The base of the radiator may become hot during running. Do not touch to
avoid hurt.
The electrical parts and components inside the VFD are electrostatic.
Take measurements to avoid electrostatic discharge during related
operation.
1.3.1 Delivery and installation
Please install the VFD on fire-retardant material and keep the VFD away
from combustible materials.
Connect the braking optional parts according to the wiring diagram.
Do not operate on the VFD if there is any damage or components loss to
the VFD.
Do not touch the VFD with wet items or body; otherwise, electric shock
may occur.
Note:
Select appropriate moving and installing tools to ensure a safe and normal running of the
VFD and avoid physical injury or death. For physical safety, the erector should take some
mechanical protective measurements, such as wearing exposure shoes and working
uniforms.
Ensure to avoid physical shock or vibration during delivery and installation.
Do not carry the VFD by its cover. The cover may fall off.
Install away from children and other public places.
The leakage current of the VFD may be above 3.5mA during operation. Ground with
proper techniques and ensure the grounding resistor is less than 10Ω. The conductivity of
PE grounding conductor is the same as that of the phase conductor. For models higher
