INVT Goodrive30 VFD Series User Manual

Goodrive30 Series VFD Function parameter list
-71-
Function
code
Name
Description
Default
Modify
11: Lower limit frequency reached
12: Ready for running
13: Pre-exciting
14: Overload pre-alarm
15: Underload pre-alarm
16: Simple PLC stage completed
17: Simple PLC cycle completed
18: Set counting value reached
19: Designated counting value reached
20: External fault is valid
21: Length reached
22: Running time reached
23: Modbus communication virtual terminal
output
24–25: Reserved
26: DC bus voltage established
27–30: Reserved
P06.05
Output
terminal
polarity
selection
The function code is used to set the polarity of
output terminals.
When a bit is 0, the input terminal is positive;
When a bit is 1, the input terminal is negative.
BIT3
BIT2
BIT1
BIT0
RO2
RO1
Reserved
Y1
Setting range: 00–0F
00
○
P06.06
Y1
switch-on
delay
Setting range: 0.000–50.000s
0.000s
○
P06.07
Y1
switch-off
delay
Setting range: 0.000–50.000s
0.000s
○
P06.10
RO1
switch-on
delay
The function code defines the delay time
corresponding to the electrical level changes
when the programmable output terminals switch
on or switch off.
0.000s
○
P06.11
RO1
switch-off
delay
0.000s
○
