Goodrive30 Series VFD Function parameter list
-34-
keypad keys, such as the RUN and STOP/RST
keys. Set the multi-function key QUICK/JOG to
FWD/REV shifting function (P07.02=3) to
change the running direction; press RUN and
STOP/RST simultaneously in running state to
make the VFD coast to stop.
1: Terminal (the "LOCAL/REMOT" indicator
blinks)
Carry out the running command control by the
forward rotation, reverse rotation and forward
jogging and reverse jogging of the multi-function
terminals.
2: Communication (the "LOCAL/REMOT"
indicator is on)
The running commands are controlled by the
upper computer in communication mode.
Used to set the max. output frequency of the
VFD. Pay attention to the function code because
it is the foundation of the frequency setting and
the speed of acceleration (ACC) and
deceleration (DEC).
Setting range: P00.04–400.00Hz
Upper limit
of running
frequency
The upper limit of the running frequency is the
upper limit of the output frequency of the VFD,
which is lower than or equal to the max. output
frequency.
When the set frequency is higher than the upper
limit of the running frequency, the upper limit of
the running frequency is used for running.
Setting range: P00.05–P00.03 (Max. output
frequency)
Lower limit
of running
frequency
The lower limit of the running frequency is the
lower limit of the output frequency of the VFD,
When the set frequency is lower than the lower
limit of the running frequency, the lower limit of
the running frequency is used for running.
Note: Max. output frequency ≥ Upper limit of
frequency ≥ Lower limit of frequency
