Goodrive30 Series VFD Function parameter list
-35-
Function
code
Name
Description
Default
Modify
Setting range: 0.00Hz–P00.04 (Upper limit of
running frequency)
P00.06
Setting
channel of
A frequency
command
Note: A frequency and B frequency cannot set
as the same frequency given method. The
frequency source can be set by P00.09.
0: Keypad
Modify the value of P00.10 (frequency set
through keypad) to set the frequency by the
keypad.
1: AI1
2: AI2
3: AI3
Set the frequency by analog input terminals. The
VFD provides 3 channels of analog input
terminals as the standard configuration, of which
AI1/AI2 is the voltage/current option
(0–10V/0–20mA) which can be shifted by
jumpers; while AI3 is voltage input (-10V–+10V).
Note: When AI1/AI2 selects the 0–20mA input,
the corresponding voltage of 20mA is 10V input.
100.0% of the analog input setting corresponds
to the max. output frequency (P00.03) in forward
direction while -100.0% corresponds to the max.
output frequency in reverse direction (P00.03).
4: High-speed pulse HDI
The frequency is set by high-speed pulse
terminals. The VFD provides 1 high speed pulse
input as the standard configuration. Range of
pulse frequency: 0.00–50.00kHz.
100.0% of the high speed pulse input setting
corresponds to the max. output frequency
(P00.03) in forward direction while -100.0%
corresponds to the max. output frequency in
reverse direction (P00.03).
Note: The pulse setting can only be input by
multi-function terminals HDI. Set P05.00 (HDI
input selection) to "High speed pulse input" and
P05.49 (HDI high-speed pulse input function
0
○
P00.07
Setting
channel of
B frequency
command
2
○
