selection) to "Frequency setting input".
5: Simple PLC program
The VFD runs at simple PLC program mode
when P00.06=5 or P00.07=5. Set P10 (Simple
PLC and multi-step speed control) to select the
running frequency, running direction, ACC/DEC
time, and the keeping time of corresponding
step. See the function description of P10 group
for detailed information.
6: Multi-step speed running
The VFD runs at multi-step speed mode when
P00.06=6 or P00.07=6. Set P05 to select the
current running step, and set P10 to select the
running frequency of the current step.
The multi-step speed has the priority when
P00.06 or P00.07 are not equal to 6, but the
setting step can only be the 1–15 step. The
setting step is 1–15 if P00.06 or P00.07 equals to
6.
7: PID control
The running mode of the VFD is process PID
control when P00.06=7 or P00.07=7. It is
necessary to set P09. The running frequency of
the VFD is the value after PID effect. See P09 for
the detailed information of the preset source,
preset value and feedback source of PID.
8: Modbus communication
The frequency is set by Modbus communication.
See P14 for detailed information.
9-11: Reserved
0: Maximum output frequency, 100% of B
frequency setting corresponds to the max. output
frequency
1: A frequency command, 100% of B frequency
setting corresponds to the max. output
frequency. Select this setting if it needs to adjust
on the base of A frequency command.
