INVT Goodrive30 VFD Series User Manual

Goodrive30 Series VFD Function parameter list
-37-
Function
code
Name
Description
Default
Modify
P00.09
Combinatio
n mode of
setting
source
0: A, the current frequency setting is A frequency
command.
1: B, the current frequency setting is B frequency
command
2: A+B, the current frequency setting is A
frequency command + B frequency command
3: A-B, the current frequency setting is A
frequency command - B frequency command
4: Max (A, B): The bigger one between A
frequency and B frequency commands is the set
frequency.
5: Min (A, B): The lower one between A
frequency and B frequency commands is the set
frequency.
Note: The combination mode can be switched
by P05 (terminal function).
0
○
P00.10
Frequency
set through
keypad
When A and B frequency commands select the
keypad for setting, the value of the function code
is the original setting one of the frequency data
of the VFD.
Setting range: 0.00 Hz–P00.03 (Max. output
frequency)
50.00Hz
○
P00.11
ACC time 1
ACC time means the time needed if the VFD
speeds up from 0Hz to the max. output
frequency (P00.03).
DEC time means the time needed if the VFD
speeds down from the max. output frequency
(P00.03) to 0Hz.
The VFD has four groups of ACC/DEC time,
which can be selected by P05. The factory
default ACC/DEC time of the VFD is the first
group.
Setting range of P00.11 and P00.12:
0.0–3600.0s
Model
depended
○
P00.12
DEC time 1
Model
depended
○
P00.13
Running
direction
0: Runs at the default direction, the VFD runs in
the forward direction. FWD/REV indicator is off.
1: Runs at the opposite direction, the VFD runs
in the reverse direction. FWD/REV indicator is
on.
0
○
