INVT Goodrive30 VFD Series User Manual

Goodrive30 Series VFD Product overview
-8-
Function
Specification
Fault protection
Provide comprehensive fault protection functions,
such as protection against overcurrent,
overvoltage, undervoltage, overtemperature,
phase loss, and overload.
Speed tracking
restart
Used to implement impact-free smooth startup for
rotating motors.
Peripheral
interface
Analog input
One input (AI2) 0–10V/0–20mA and 1 input (AI3)
-10–10V.
Analog output
Two inputs (AO1 and AO2) 0–10V/0–20mA.
Digital input
Four regular inputs; max. frequency: 1kHz;
One high-speed input; max. frequency: 50kHz
Digital output
One Y1 terminal output
Relay output
Two programmable relay outputs:
RO1A: NO; RO1B: NC; RO1C: common terminal;
RO2A: NO; RO2B: NC; RO2C: common terminal.
Contact capacity: 3A/AC250V
Others
DC reactor
DC reactors have been built in the 18.5kW and
higher VFD models as standard configuration.
Installation mode
Wall and rail installation for the 1PH 220V/3PH
380V (≤2.2KW) and 3PH 220V (≤0.75KW) VFD
models.
Wall and flange installation for the 3PH 380V
(≥4kW) and 3PH 220V (≥1.5kW) VFD models.
Braking unit
Braking units have been built in the 37kW and
lower VFD models as standard configuration.
Braking units have been built in the 45–110kW
VFD models as optional configuration.
EMI filter
3PH 380V (≥4kW) and 3PH 220V (≥1.5kW) VFD
models can satisfy the requirements of IEC
61800-3 C3, other models can satisfy the
requirements of IEC 61800-3 C3 by installing
optional external filter. The whole series can
satisfy the requirements of IEC 61800-3 C2 by
installing optional external filter.
Temperature of
running
environment
-10–+50°C; derating is required if the ambient
temperature exceeds 40°C.
