INVT Goodrive30 VFD Series User Manual

Goodrive30 Series VFD Optional peripheral accessories
-159-
from the breaker enclosure when a short-circuit occurs. To ensure safe
use, exercise extra caution when installing and placing the breaker.
Follow the manufacturer's instructions.
To ensure safety, you can configure an electromagnetic contactor on the input side to control
the switch-on and switch-off of the main circuit power, so that the input power supply of the
VFD can be effectively cut off when a system fault occurs.
VFD model
Fuse
(A)
Breaker
(A)
Contactor rated
current
(A)
GD30-0R4G-S2
10
10
9
GD30-0R7G-S2
16
16
12
GD30-1R5G-S2
25
25
25
GD30-2R2G-S2
50
40
32
GD30-0R4G-2
6
6
9
GD30-0R7G-2
10
10
9
GD30-1R5G-2
16
16
12
GD30-2R2G-2
25
25
18
GD30-004G-2
35
32
25
GD30-5R5G-2
35
32
32
GD30-7R5G-2
50
63
50
GD30-0R7G-4
6
6
9
GD30-1R5G-4
10
10
9
GD30-2R2G-4
10
10
9
GD30-004G-4
25
25
25
GD30-5R5G-4
35
32
25
GD30-7R5G-4
50
40
38
GD30-011G-4
63
63
50
GD30-015G-4
63
63
50
GD30-018G-4
100
100
65
GD30-022G-4
100
100
80
GD30-030G-4
125
125
95
GD30-037G-4
150
160
115
GD30-045G-4
150
200
170
GD30-055G-4
200
200
170
GD30-075G-4
250
250
205
GD30-090G-4
325
315
245
GD30-110G-4
350
350
300
