INVT Goodrive30 VFD Series User Manual

Goodrive30 Series VFD Optional peripheral accessories
-166-
VFD model
Braking
unit
model
Resistance
applicable
for 100%
brake torque
(Ω)
Dissipated power of braking resistor
(kW)
Min.
allowable
brake
resistance
(Ω)
10% brake
usage
50% brake
usage
80% brake
usage
GD30-1R5G-4
326
0.23
1.13
1.80
170
GD30-2R2G-4
222
0.33
1.65
2.64
130
GD30-004G-4
122
0.6
3
4.8
80
GD30-5R5G-4
89.1
0.75
4.13
6.6
60
GD30-7R5G-4
65.3
1.13
5.63
9
47
GD30-011G-4
44.5
1.65
8.25
13.2
31
GD30-015G-4
32.0
2.25
11.3
18
23
GD30-018G-4
27
3
14
22
19
GD30-022G-4
22
3
17
26
17
GD30-030G-4
17
5
23
36
17
GD30-037G-4
13
6
28
44
11.7
GD30-045G-4-B
10
7
34
54
8
GD30-055G-4-B
8
8
41
66
8
GD30-075G-4-B
6.5
11
56
90
6.4
GD30-090G-4-B
5.4
14
68
108
4.4
GD30-110G-4-B
4.5
17
83
132
4.4
Note：
 Select braking resistors according to the resistance and power data provided by our
company.
 The braking resistor may increase the brake torque of the VFD. The preceding table
describes the resistance and power for 100% brake torque, 10% brake usage, 50% brake
usage, and 80% brake usage. You can select the braking system based on the actual
operation conditions.
 Do not use braking resistors whose resistance is lower than the specified
minimum resistance. The VFD does not provide protection against
overcurrent caused by resistors with low resistance.
 In scenarios where brake is frequently implemented, that is, the brake
usage is greater than 10%, you need to select a braking resistor with
higher power as required by the operation conditions according to the
preceding table.
