Communication
USER MANUAL FPC 200 - 3/2017 109
ASDU
FUN
INF
COT
GI
IEC 60870-5-103 semantic
FPC 200 semantic
Voltage protections
2
102
1
1
Protection UV 1 [27 - 1]
2
102
2
1
Protection UV 2 [27 - 2]
2
102
3
1
Protection RUV [27R]
2
102
4
1
Protection PSUV 1 [27D - 1]
2
102
5
1
Protection PSUV 2 [27D - 2]
2
102
6
1
Protection OV 1 [59 - 1]
2
102
7
1
Protection OV 2 [59 - 2]
2
102
8
1
Protection NVD 1 [59NG - 1]
2
102
9
1
Protection NVD 2 [59NG - 2]
2
102
10
1
Protection NVD 1 [59NG - 3]
2
102
11
1
Protection NVD 2 [59NG - 4]
Frequency protections
2
103
1
1
Protection OF 1 [81H - 1]
2
103
2
1
Protection OF 2 [81H - 2]
2
103
3
1
Protection UF 1 [81L - 1]
2
103
4
1
Protection UF 2 [81L - 2]
2
103
5
1
Protection UF 3 [81L - 3]
2
103
6
1
Protection UF 4 [81L - 4]
2
103
7
1
Protection ROCOF [81R]
Motor/generator protections
2
104
1
1
Protection TO [49T]
2
104
2
1
Protection MTO [49M]
2
104
3
1
Protection LR [48/51LR/14]
2
104
4
1
Protection SPH [66]
Miscellaneous protections
2
105
1
1
Protection EXT 1
2
105
2
1
Protection EXT 2
2
105
3
1
Thermostat 1
2
105
4
1
Thermostat 2
2
105
5
1
Buchholz 1
2
105
6
1
Buchholz 2
Thermal protections
2
106
1
1
Protection TMO 1 [38/49T - 1]
2
106
2
1
Protection TMO 2 [38/49T - 2]
2
106
3
1
Protection TMO 3 [38/49T - 3]
2
106
4
1
Protection TMO 4 [38/49T - 4]
2
106
5
1
Protection TMO 5 [38/49T - 5]
2
106
6
1
Protection TMO 6 [38/49T - 6]
2
106
7
1
Protection TMO 7 [38/49T - 7]
2
106
8
1
Protection TMO 8 [38/49T - 8]
2
106
9
1
Protection TMO 9 [38/49T - 9]
2
106
10
1
Protection TMO 10 [38/49T - 10]
2
106
11
1
Protection TMO 11 [38/49T - 11]
2
106
12
1
Protection TMO 12 [38/49T - 12]
2
106
13
1
Protection TMO 13 [38/49T - 13]
2
106
14
1
Protection TMO 14 [38/49T - 14]
2
106
15
1
Protection TMO 15 [38/49T - 15]
2
106
16
1
Protection TMO 16 [38/49T - 16]
Table 107 Data table of the standard protocol IEC60870-5-103, monitor direction.
