Communication
110 USER MANUAL FPC 200 - 3/2017
ASDU
FUN
INF
COT
GI
IEC 60870-5-103 semantic
FPC 200 semantic
Standard measurements
9
160
148
2
MEA1: Phase current I1
MEA1: Phase current I
L1
MEA2: Phase current I2
MEA2: Phase current I
L2
MEA3: Phase current I3
MEA3: Phase current I
L3
MEA4: Phase voltage U1
MEA4: Phase voltage U
L1
MEA5: Phase voltage U2
MEA5: Phase voltage U
L2
MEA6: Phase voltage U3
MEA6: Phase voltage U
L3
MEA7: Active power P
MEA7: Active power P
MEA8: Reactive power Q
MEA8: Reactive power Q
MEA9: Frequency f
MEA9: System frequency f
Custom measurements
9
11
1
2
MEA1: Earth current I
e
MEA2: Phase to phase voltage U
12
MEA3: Phase to phase voltage U
23
MEA4: Phase to phase voltage U
31
MEA5: Earth voltage U
e
MEA6: Positive sequence current I
1
MEA7: Negative sequence current I
2
MEA8: Zero sequence current I
0
MEA9: 3xZero sequence current 3xI
0
MEA10: Positive sequence voltage U
1
MEA11:
Negative sequence voltage U
2
MEA12: Zero sequence voltage U
0
MEA13:
3xZero sequence voltage 3xU
0
Temperature measurements
9
10
1
2
MEA1: Temperature sensor 1
MEA2: Temperature sensor 2
MEA3: Temperature sensor 3
MEA4: Temperature sensor 4
MEA5: Temperature sensor 5
MEA6: Temperature sensor 6
MEA7: Temperature sensor 7
MEA8: Temperature sensor 8
MEA9: Temperature sensor 9
MEA10: Temperature sensor 10
MEA11: Temperature sensor 11
MEA12: Temperature sensor 12
MEA13: Temperature sensor 13
MEA14: Temperature sensor 14
MEA15: Temperature sensor 15
MEA16: Temperature sensor 16
Table 108 Data table of the standard protocol IEC60870-5-103, monitor direction.
