Settings
USER MANUAL FPC 200 - 3/2017 137
To browse Ethernet devices
On program interface Connection in group Searching
click on Browse Ethernet devices.
If device IP address matches the PC subnet mask, this
device will appear on the list in black colour, otherwise
in red colour. Communication (measurements, settings,
analyses) with red coloured devices is not possible.
To change the device IP address
1. Select the device from the list,
2. Change communication parameters in a table
on the right side of the list (for IP Port setting
take in to consideration Port numbers table
below).
3. Click on Download settings button in the
toolbar.
To change the IP address for device not on list
1. Click on Assign IP by MAC button,
2. Enter MAC address on the Ethernet settings
form,
3. Enter IP address on the Ethernet settings form
or select Automatic (DHCP),
4. Enter Local port number on the Ethernet
settings form. Use a recommended port
numbers from the following table. If using
Redirector software, the port number should
be between 14000 and 14009.
5. Click on OK button. Adapter initialization takes
a few seconds.
Table 110 Ethernet port configuration.
4.3.2.2.7 Favorited connections
For quick access to device, list of favourite connections can be used. Device will be added to the list of favourite
connections every time communication with a device is established. The list can contain up to 32 last used connections. It
is possible to rename connection on a list, to make the work easier.
To select device from favourite connections list
1. Click on dropdown combo Go to in toolbar and select the device (connection).
To rename or remove device from list
2. Click on label Go to in toolbar and choose Rename.
3. Click on label Go to in toolbar and choose Delete Selected connection or All connections.
4. On dropdown menu:
a. Select the connection you want to rename or delete,
b. Click on Rename button and enter new name, if you want to rename Selected connection,
5. Click on Delete button and select, if you want to delete Selected connection or All connections.
4.3.2.2.8 Adding the device to My Devices list
Devices that are frequently used can be added to user defined list in My devices. From My devices access to device
settings and downloaded or recorded files is much easier.
Adding device to the list
To add the device to the list first establish
communication with the device, then click Add to
My devices icon. The Device properties window will
appear, that will give the user possibility to:
Assign the device to predefined device group.
Give the device user defined description and
location for easier recognition.
Change default data directory and enable
subdirectories structure for downloaded data.
By click on the OK button settings are confirmed. Device
can now be found in My Devices.
