Settings
USER MANUAL FPC 200 - 3/2017 139
4.3.2.3.2 Downloading the settings
To download settings, the communication connection to
the device must be established. You can choose
between three download options:
Download settings – all settings from MiQen
settings table will be downloaded into device.
Download settings (Only changes) – only new,
changed settings from MiQen settings table will
be downloaded into device.
Download group – only settings from selected
group will be downloaded.
There is no difference between options A and B when
the settings are read from device. If the settings were
opened from settings file in first case (A) all settings will
be downloaded. In the second case (B) only new,
changed settings will be downloaded.
To download all settings (A)
Choose one of the following:
Click on Download settings button on
toolbar,
Select Download settings from File menu or
press Ctrl+D,
Right-click on settings table and select
Download settings from context menu,
To download only changed settings (B)
Choose one of the following:
Select Download settings (Only changes) from
File menu,
Right-click on settings table and select
Download settings (Only changes) from
context menu.
To download group settings (C)
Right-click on selected group in settings tree
structure and select Download group.
If device is protected with password, you must enter
correct password for required level of access before
downloading.
When settings in device memory are changed,
the warning message will appear before
download. Continue only, if the memory has
already been read, otherwise memory data
might be lost or wrong values may appear on
changed locations!
Download status window with progress bar will
appear during download. Click on Details button
after download is finished to look at changed
registers or Close button to close the window.
Window with details will appear in case of
errors or warnings automatically after transfer,
to help solve problems.
